To help ensure smooth-running operations, Vermeer offers everything you need from one-day training seminars to computer software for more efficient bore planning and performance. At any given time, more than half of all horizontal directional drilling units in the world are Vermeer NAVIGATOR machines. governed speed: 2400 RPM Drill Stem Type: FIRESTICK II Length: 15 (4.6 m) or 10 (3 m) Joint diameter: 2.75 (7 cm) Pipe diameter: 15 (4.6 m) (7 cm) Pipe diameter: 10 (3 m) (6 cm) Minimum bend radius: 15 (4.6 m) (44 m) Minimum bend radius: 10 (3 m) 108 (33 m) Weight: 15 (4.6 m) 143 lb (65 kg) Weight: 10 (3 m) 81 lb (36.7 kg) Rod carrying capacity: 15 (4.6 m) 600' (183 m) Rod carrying capacity: 10 (3 m) 520 (159 m) Fluid Capacities Engine oil (including filter): 15.5 qt (14.7 L) Fuel tank: 42 gal (159 L) Hydraulic reservoir: 55 gal (208 L) Water Pump Options 50 gpm (189 L/pm) Aplex Mud Pump 50 gpm (189 L/pm) FMC Mud Pump 70 gpm (318 L/pm) Aplex Mud PumpĦ Vermeer offers everything from specialty tooling to training and technology.
#Vermeer Atlas Bore Planner series
The Vermeer FieldCalc system combines software and a handheld computer to provide job site calculations, including setback distance, pullback time and point-topoint calculations.ĥ D36x50 Series II Specifications General Length: 15 (4.6 m): 277" (704 cm) Length: 10 (3 m): 212 (538 cm) Width (fixed tracks): 82" (208 cm) Height: 10 (3 m): 75" (191 cm) Weight (15 /4.6 m): 21,920 lb (9943 kg) Weight (10 /3m): 19,800 lb (8981 kg) Breakout system: Power-vise Stakedown system: Stationary, dual stakes Operational Max spindle torque: 4995 ft-lb (6772 Nm) Max spindle speed: 206 RPM Thrust (actual): 36,000 lb (16,329 kg) Pullback (actual): 36,000 lb (16,329 kg) Carriage Speed: 175 fpm (53 m/min) Power Engine: John Deere Diesel 4045 (4.5L) Tier II Turbo Gross hp: 140 hp (104 kw) Max.
Vermeer ATLAS BORE PLANNER software heightens professionalism by aiding the operator in preplanning the bore and comparing the planned bore path with the actual bore path. The efficient, economical way to plan a bore. Vermeer offers specially formulated nontoxic polymer and bentonite drilling fluids to get the job done.
Wetting agents, polymers, and bentonites you need the right mix to get through the tough bores. An exclusive steel formula increases rod memory and reduces flex fatigue for added rod life and dependability. Vermeer one-piece, forged FIRESTICK rods feature threads designed specifically for directional boring. Various fluid mixing systems are available. FIRESTICK II drill stem is designed to handle high torque while retaining a large inside diameter for superior drilling fluidflow. See policy for details Rod Carrying Capacity: The D36x50 Series II carries 600 (183 m) of one-piece FIRESTICK II drill stem in 15 foot (4.5 m) lengths, or 520 foot (158.5 m) of one-piece FIRESTICK II drill stem in 10 foot (3 m) lengths. Exludes carraige, carraiage rollers and guide rollers. Vermeer offers you peace of mind by providing additional lifetime limited warranty protection on all rack and pinion gears.* * Covered components: all rack gears and pionion gears. In addition to the Vermeer Equipment Limited Warranty. For precise fingertip control, the electronic joystick controls that administer thrust and rotation also operate the on-board drilling fluid pump, breakout system and throttle operations.Ĥ Protect your investment. A narrow rack and pinion design helps to maintain small footprint for access into congested areas. With the highest power-to-size ratio in its class, the D36x50 Series II is powered by a 140 hp (104 kw) engine and delivers 4995 ft-lb (6681 Nm) of rotary torque and 36,000 lb (16,329 kg) of thrust and pullback. Designed for comfort and efficiency, the D36x50 Series II offers an elevated, manually operated swing-out seat.
Ergonomically designed operator s station. A pivoting one-piece fiberglass hood provides easy access to the engine and hydraulics compartment. With the highest power-to-size ratio in its class and narrowly designed rack and pinion, the D36x50 Series II is built to perform a wide range of medium diameter, mid-to-long distance utility installations. When you need a midsized drill with big features, look no further than the Vermeer D36x50 Series II NAVIGATOR HDD with 10 foot (3 m) and 15 foot (4.5 m) rack options.
